- Fully manual belt-drive operation with 33 1/3 and 45 rpm speeds
- Motor features a speed sensor system to help maintain accurate platter rotation speed
- Adjustable dynamic anti-skate control
- Anti-resonance, die-cast aluminum platter with rubber mat
- AT-HS4 universal 1/2" mount headshell and AT-VM95E Dual Moving Magnet phono cartridge with elliptical stylus
- Included cartridge is compatible with nearly any VM95 series replacement stylus
- Straight carbon-fiber tonearm with hydraulically damped lift control and lockable rest
- Anti-resonance plinth with walnut simulated wood veneer
- Switchable built-in preamplifier for phono- or line-level output
- AC adapter handles AC/DC conversion outside the chassis, helping to reduce noise in the signal chain.
Specifications
| Motor | DC Servo |
| Drive Method | Belt Drive |
| Speeds | 33 1/3, 45 rpm |
| Tonearm Type | Straight |
| Effective Arm Length | Tonearm: 8.8" / 223.6 mm |
| Overhang | 18.6 mm |
| Tracking Error Angle | <2° |
| Cartridge Weight | Applicable: 12 to 17 g |
| Anti-Skating Range | 0 to 3 g |
| Signal to Noise Ratio | >60 dB |
| Wow and Flutter | 0.15% (WTD) @ 3 kHz (JIS) |
| Headshell | 1/2" Mount |
| Stylus | Type: 0.3 x 0.7 Mil Elliptical Replacement: AT-VMN95E |
| Connectors | 1 x Stereo RCA Phono / Line Pair (Switchable Preamplifier) |
| Gain | Phono Preamp: 35 dB Nominal, RIAA Equalized |
| Output Level | Phono: 4 mV Nominal at 1 kHz, 5 cm/sec Line: 200 mV Nominal at 1 kHz, 5 cm/sec |
| Turntable Platter | Die-Cast Aluminum |
| Construction Material | Plinth: MDF Tonearm: Carbon-Fiber |
| Power Requirements | 100 to 240 VAC, 60 Hz |
| Power Consumption | 1 W |
| Dimensions (W x H x D) | 17.13 x 5.04 x 13.9" / 420 x 116.9 x 340 mm |
| Weight | 10.4 lb / 4.7 kg |
| Package Weight | 13.6 lb |
| Box Dimensions (LxWxH) | 19.4 x 16.3 x 7.5" |
